Vieworks Vivix DR Plates[21667]

17 x 17" DR Flat Plate Digital Imaging System (Tethered & Wireless)

The large DR Flat Plate Imaging system, only 15mm thin, light weight, cassette sized flat panel DR detector, with maximum surface area coverage to completely capture even the largest sized foot.

The extra image capture area allows your existing x-ray machine to become an advanced digital x-ray system with easy placement and more coverage than normal 10 x 12" systems, but without the premium cost.

The larger DR Flat Plates have the same dimensions as a standard ISO 4090 film cassette, and fits into existing cassette and Bucky trays.

No Cable connection is required with your x-ray generator to synchronize signals, as the AED, (Auto Exposure Detection) handles exposure timing.

Benefits

  • ACC (Auto Calibration Control)
    Calibration data is embedded in the detector. Periodic calibration or recalibration of the detector can generate many service issues in DR retrofits. This tedious and time consuming step requiring a trained engineer is eliminated.
  • AED (Automatic Exposure Detection)
    Detector is equipped with Automatic Exposure technology which does not need generator connection to synchronize the exposure signal. AED skips these steps and allows all brands and models of x-ray generators to be upgraded.
  • Easy Updates
    The future is built in....evolution by design. This is state of the art, however technologies in this detector are evolving every day. The USB port is the window to update firmware and other functions without having to send the detector anywhere.
  • Flexibility
    Works with all types of x-ray generators...from all manufacturers. Both wired and wireless connectivity available.
  • Imaging Software
    HIPAA compliant imaging software which produces high quality DICOM images in seconds, custom measurement capability, works with virtually all EMR practice management software, and remote internet viewing capability.
VetDRpic1
VetDRpic2

Video Demonstration

Play Video
Play Video

14 x 17" DR Flat Plate Digital Imaging System (Tethered & Wireless)

A system so simple, it requires no connection to the generator, no calibration, and no wireless setup with your router. A standard laptop or PC and our detector...works with any x-ray source you have.

vivixpanel

Benefits

  • ACC (Auto Calibration Control)
    Calibration data is embedded in the detector. Periodic calibration or recalibration of the detector can generate many service issues in DR retrofits. This tedious and time consuming step requiring a trained engineer is eliminated.
  • AED (Automatic Exposure Detection)
    Detector is equipped with Automatic Exposure technology which does not need generator connection to synchronize the exposure signal. AED skips these steps and allows all brands and models of x-ray generators to be upgraded.
  • Easy Updates
    The future is built in....evolution by design. This is state of the art, however technologies in this detector are evolving every day. The USB port is the window to update firmware and other functions without having to send the detector anywhere.
  • Flexibility
    Works with all types of x-ray generators...from all manufacturers. Both wired and wireless connectivity available.
  • Imaging Software
    HIPAA compliant imaging software which produces high quality DICOM images in seconds, custom measurement capability, works with virtually all EMR practice management software, and remote internet viewing capability.

BIO-RAY Medallion Intraoral Digital X‑Ray Sensor

(5th generation Bio-Ray) with the latest advanced CsI, (Cesium Iodide) & fiber optic plate technology for the capture of high quality Dental intra-oral x-ray images. A sturdy sensor with cut corners for patient comfort, shortest time, reduced patient radiation, & direct USB connection allowing a wide range of exposure settings, resulting in consistent & diagnosable images.

  • Two sizes
  • Water-resistant
  • Direct USB connection (no USB connection box)



  • The Bio-Ray Medallion is available in two sizes: Size 1 with a sensitive (active) area of 30 x 20 mm (ideal for children and tight areas).
  • Size 2, with a sensitive (active) area of 33 x 25 mm: a larger surface area for standard examinations.
medallion12nb
medallionbw
medallionspecs
medallion12nb
clariushandsholding

Sigma: Next Generation Clarius Handheld Wireless Ultrasound

The Clarius Handheld Ultrasound Scanner is purpose‑built to provide a detailed picture of superficial anatomy with your Apple IOS / Android phone or tablet

Value Priced @ Only $4,900.00
Call or Email Now to Order, & Receive a Free Accessory Bonus or Interest free financing!

Add Revenue to Your Practice at less than 1/3 the Cost of Expensive Cart Systems

clariusx3
smalldog-1 (1)
artery-1 (1)

Click here for more clinical images

  • Image Quality Matters:
    Best in Class, Equal to or Better than Cart Based Systems. Designed to provide exceptionally detailed imaging of superficial structures, the Clarius L7, C7, & C3 wireless handheld ultrasound is ideal for plastic surgeons, microsurgeons, pediatricians, hematologists, podiatrists, rheumatologists, and other specialty physicians who currently rely on costly cart-based systems to visualize shallow anatomy.
  • Wireless Freedom:
    Focus on scanning your patient without wires getting in the way. Clarius Scanners use WIFI direct to connect to the easy to use IOS or Android apps. (No wifi router needed)
  • Telemedicine made simple:
    With Clarius Live, you can send a link to enable recipient, (Sonographer) to view your scan remotely live and direct technicians’ movement.
  • Durable and Watertight:
    With no moving parts or cables and a drop-safe magnesium shell, you don't have to worry about using Clarius in demanding clinical settings. They are sterilizable and submersible to 3 feet.
  • Cloud Storage: Manage Your Exams Online
    Send your ultrasound exam to Clarius Cloud after you’re done scanning. Access your exams stored in the Clarius Cloud from anywhere you have an Internet Connection. Make notes, send exams for review, export PDF reports and more. Unlimited & free.
  • Included Free:
    No Annual Subscription Fees, Color & Power Doppler imaging, B & M modes, 1-Click Telemedicine, Auto AI, Video & Freeze Capture, Unlimited Cloud Storage (with free access to make & send detailed reports), 3 Year warranty.
  • Optional:
    Ultra High-Frequency (8-20 MHz), DICOM sending capability, auditory color pulse wave doppler, & MSK presets.

Video Demonstrations

clariusholder

More Videos & Links:

Canine Spleen Ultrasound
Cat Cardiac Ultrasound Tutorial

Dog Bowel Ultrasound Tutorial
Clarius-Included Ultrasound Telemedicine

Clarius Live - Ultrasound Telemedicine Made Simple (PDF)
Clarius Free Cloud Storage

SkanRay RayOs-DC High Frequency Intra-Oral X-Ray System

Skanray

User Interface

  • Graphic LCD display, (switchable to human or vet)
  • Factory set parameters for film, digital sensor, and PSP
  • Three custom settings for the user to store preferred settings
  • Option to select short and long cone for exposure
  • Anatomy selection option
  • kV settable from 55 to 70 (fixed at 65 by default)
  • mA settable from 4 to 8 in steps of 1mA
  • Capable of working with two consoles (internal and external)
  • Option to integrate doorbell switch with external console for two-hand operation
  • Audio/visual exposure warning system
  • Feedback of actual exposure parameters
skanray

Finish and Ergonomics

  • High gloss easy to clean plastic parts
  • High gloss polyurethane paint for durability and ease of cleaning
  • Design without brakes avoiding field adjustments
  • Clear graphic display for user-friendly interfacing
  • Multiple arm lengths to suit the requirements of every clinic
  • Heavy casted base for the stability of mobile units
  • Settings either from internal or external console working simultaneously

Balanced and Stable Arm

  • Arm stable over 200,000 cycles of operation
  • Available with 24 in. short, or 32 in. long arm
  • Easy external adjustment of arm
  • Cable life of over 200,000 operations

Complete Focus Control

Remote Control Options

  • X-ray control with internal console and dead man switch only
  • X-ray control with internal and external console connected through RJ45 (8P8C)
  • X-ray control with internal and external console, and doorbell switch for two-switch operation (external console and doorbell switch connects through 3 wires)
  • Internal console and external doorbell switch through RJ11(6P4C) or 3 wire.

Wide Input Range With PFC Correction

  • PFC makes input current clean with low harmonic content
  • Unit works from 99V to 253 V AC giving constant and stable X-ray output

SkanRay Specifications:

Tube Insert Model: OX/70-5
Focal Spot (IEC60336): 0.4mm IEC
Anode Material: Tungsten
Anode Angle: 19°
Insert Inherent Filtration: 0.5 mm Al Equivalent @ 70 kV
Anode Thermal Capacity: 7 kJ
Tube Voltage: 60kV - 70kV Settable (Step Size 1kV)
Source to Skin Distance: 9" +/- 0.2", 12.2" +/- with Cone Attachment
Weight (Packed): Wall Mount: 110 lbs., Mobile: 222 lbs./td>
Height (With Arms Folded): 51" +/- 0.5"
Long Arm Rotation: 180 deg. +/- 10 deg.
Scissor Arm Swing (Wall Mount): 220 deg. +/- 10 deg.
Scissor Arm Swing (Mobile): 70 deg. +/- 10 deg.
Tube-Head Swivel (Horizontal): 530 deg. +/- 10 deg.
Tube-Head Rotation (Vertical): 305 deg. +/- 5 deg.

Complies With Global Standards: UL, CE, FDA, Health‑Canada, AERB.

Low Leakage Radiation and Patient Dose

  • Leveraging of DC technology to reduce soft radiation and exposure time
  • Patented shielding method which makes leakage close to zero at 1mt distance
  • Recessed X-ray tube for ease of positioning for certain anatomy
  • Built-in safety to avoid unintentional X-ray exposure

Veterinary

Sigma DR X-Ray systems operate with VXVue imaging software.

Important features:

  • Superior Image Quality.
  • HIPAA Compliant
  • Not merely "DICOM Compliant"....we actually produce DICOM and EMR compliant images.
  • DICOM PACS server
  • Wide selection of measuring tools available for Podiatry, Veterinary, & Chiropractic.
  • Database remote access capable.
  • Stitching feature combining multiple images into one.
  • Touchscreen monitor and tablet capabilty.
vxvuevet1
vxvue
