14 x 17" DR Flat Plate Digital Imaging System (Tethered & Wireless)

A system so simple, it requires no connection to the generator, no calibration, and no wireless setup with your router. A standard laptop or PC and our detector...works with any x-ray source you have.

Benefits

ACC (Auto Calibration Control)
Calibration data is embedded in the detector. Periodic calibration or recalibration of the detector can generate many service issues in DR retrofits. This tedious and time consuming step requiring a trained engineer is eliminated.
AED (Automatic Exposure Detection)
Detector is equipped with Automatic Exposure technology which does not need generator connection to synchronize the exposure signal. AED skips these steps and allows all brands and models of x-ray generators to be upgraded.
Easy Updates
The future is built in....evolution by design. This is state of the art, however technologies in this detector are evolving every day. The USB port is the window to update firmware and other functions without having to send the detector anywhere.

Flexibility
Works with all types of x-ray generators...from all manufacturers. Both wired and wireless connectivity available.
Imaging Software
HIPAA compliant imaging software which produces high quality DICOM images in seconds, custom measurement capability, works with virtually all EMR practice management software, and remote internet viewing capability.

Video Demonstration

Play Video

17 x 17" DR Flat Plate Digital Imaging System (Tethered & Wireless)

The large DR Flat Plate Imaging system, only 15mm thin, light weight, cassette sized flat panel DR detector, with maximum surface area coverage to completely capture even the largest sized foot.

The extra image capture area allows your existing x-ray machine to become an advanced digital x-ray system with easy placement and more coverage than normal 10 x 12" systems, but without the premium cost.

The larger DR Flat Plates have the same dimensions as a standard ISO 4090 film cassette, and fits into existing cassette and Bucky trays.

No Cable connection is required with your x-ray generator to synchronize signals, as the AED, (Auto Exposure Detection) handles exposure timing.

Benefits

ACC (Auto Calibration Control)
Calibration data is embedded in the detector. Periodic calibration or recalibration of the detector can generate many service issues in DR retrofits. This tedious and time consuming step requiring a trained engineer is eliminated.
AED (Automatic Exposure Detection)
Detector is equipped with Automatic Exposure technology which does not need generator connection to synchronize the exposure signal. AED skips these steps and allows all brands and models of x-ray generators to be upgraded.
Easy Updates
The future is built in....evolution by design. This is state of the art, however technologies in this detector are evolving every day. The USB port is the window to update firmware and other functions without having to send the detector anywhere.

Flexibility
Works with all types of x-ray generators...from all manufacturers. Both wired and wireless connectivity available.
Imaging Software
HIPAA compliant imaging software which produces high quality DICOM images in seconds, custom measurement capability, works with virtually all EMR practice management software, and remote internet viewing capability.

Sigma DR X-Ray systems operate with VXVue imaging software.

Important features:

Superior Image Quality.
HIPAA Compliant
Not merely "DICOM Compliant"....we actually produce DICOM and EMR compliant images.
DICOM PACS server
Wide selection of measuring tools available for Podiatry, Veterinary, & Chiropractic.
Database remote access capable.
Stitching feature combining multiple images into one.
Touchscreen monitor and tablet capabilty.

AirRay-20 INTRODUCING THE NEW STANDARD IN MEDICAL IMAGING

THE LIGHTEST, THE STRONGEST, AirRay-20

TRUE FULL BODY IMAGING

What’s in the case?
• Generator
• Hand switch
• External charging bank
• Car charger
• USB-A and USB-C cables
• USB extension cable
• Remote control software
• USB-A port for bluetooth connectivity
• Plug adapter
• Power cable
• Skin guard
• Carry strap

Wireless Charging
Three ways to charge so you are never without power -including in the case!
Built in LED Collimator with laser pointer
Remote control software
USB-A port for Bluetooth communication

MODEL	AIRRAY-20
Output(kW)	1.6
kV Range per 1kV step mA	50-90
mA Range/No. of step	8-20/5
mAs Range/No. of step	0.4-20/25
Tube Focal Spot(mm)	1.0 x 1.0
Target Angle	16°
Duel Laser Pointer	Standard
Battery	3.7V/5,000mAh (2 x supplied)
Charge Time	3 Hours
No. of APR	10
Weight	11 lbs

MS-1500 Mobile Carts for the AirRay-20

X-Cel 715-BD X-Cel 715-BD Series Podiatry X-Ray

The newest easy-to-use feature is the patented Tilt-Head, which enables the user to tilt the x-ray source.

Tilt-Head units:

Eliminate the need to rotate the patient for the DP view
Patient support rail allows access from side or fron
Eliminate the need to rotate the arm for the AP view
Eliminate the need to readjust the collimator lateral views
Enable wheelchair patients to be easily accommodated without having to leave the wheelchair
Feature the low voltage expose switch with optional remote key box Include features that can meet ADA guidelines (consult your accountant)

3.5-inch base height
28-inch SID
Saves floor space
3.5-inch base height
Fits between wall and chair
Minimum space required: 34" x 51"
Both laterals possible
Folds to 18 inches wide
15 mA
50-70 kVp
Available in white

Play Video

X-Cel HF-718-BD X-Cel High Frequency HF-718-BD Series Podiatry X‑Ray

The newest easy-to-use feature is the patented Tilt-Head, which enables the user to tilt the x-ray source.

Tilt-Head units:

Eliminate the need to rotate the patient for the DP view
Patient support rail allows access from side or fron
Eliminate the need to rotate the arm for the AP view
Eliminate the need to readjust the collimator lateral views
Enable wheelchair patients to be easily accommodated without having to leave the wheelchair
Feature the low voltage expose switch with optional remote key box Include features that can meet ADA guidelines (consult your accountant)

3.5-inch base height
28-inch SID
Saves floor space
3.5-inch base height
Fits between wall and chair
Minimum space required: 34" x 51"
Both laterals possible
Folds to 18 inches wide
15 mA
50-70 kVp
Available in white

SDR+ Straight Arm Flexible System Design

A wide range of movement, making nearly any examination possible
- Detector tilting: +/- 45 °
- Arm rotation: -30° – 120°
- Tube rotation: +/- 90°
Fast motorized SID adjustment: 40” to 72”
Counter-balanced unit that can be smoothly positioned
Ideal for facilities with a limited amounts of space
- Less than 7 feet tall, the system comfortably fits into rooms with 8’ ceilings
Chin guard for enhanced patient comfort
System can plug directly into a residential power outlet
- No need to worry about additional power

Additional Features

Intuitive 10” touchscreen display simplified system operation
Up to 60 semi-automatic pre-set positions of stand height, orientation, and SID
Removable grid
Integrated High Frequency X-ray Generator, with customized Anatomical Programming (APR) from the digital technologist workstation
Integrated high performance digital flat panel DR detector, with fast image display and exceptional image quality
Occupies the smallest footprint within an 8” ceiling without limiting full-functionality
Technologist friendly features with collimator and system movement and collision sensors
Integrated safety features with multiple emergency-stop buttons and collision sensors
Optional: Lightweight mobile patient imaging table, (max. Patient weight 516lbs.)
Optional (AEC) Automatic Exposure Control
Dual laser LED collimator

Unlimited Exam Possibilities

Quick, easy stand positioning along with motorized source-image-distance (SID) adjustment enables a wide spectrum of upright imaging of the chest, abdomen and other skeletal exams as well as supine imaging of patients on the optional mobile table including various oblique techniques. Ergonomic user interface with multi-language support, simple APR technique selection with automated exposure parameter adjustment settings for patient size, enable a high patient throughput. The Medlink SDR+ offers a unique feature-rich design making it universally useful in all applications of diagnostic radiography.

Features with Patient Comfort in Mind

The Medlink SDR+, is a digital radiography (DR) system designed for a wide range of general and specialized diagnostic imaging.

The Semi-automated, pre-programmed positioning allows for maximum efficiency, allowing for up to 60 customized,
pre-programmed positions of any exam type. The enclosed Digital flat panel detector offers flexible imaging of all anatomy with superior resolution at industry leading lower doses. The Medlink SDR+ Integrated 10” touch screen display console automatically controls all system components while providing the operator with unprecedented simplicity and ease-of-use. Whether working in a general radiology or orthopedic application, the Medlink SDR+ system provides the user with customized workflow, unmatched functionality and exceptional diagnostic quality.

Standard Features, Budget-Friendly Price

The Medlink SDR is also offered in our Standard configuration. Offering the same versatility and exception digital imaging quality as the Medlink SDR+, with our standard non-touchscreen display, no programmable auto-positions and limited workflow features.

Workstations

Featuring the VIVIX-S 1717V DR solution and a ready-to-go plug and play Dell Monitor.
Workstations includes 5-year manufacturer’s warranty.
